VADDIO

VADDIO REVEAL IN-WALL PTZ CAMERA 998-6925-000 - PREOWNED

VADDIO REVEAL IN-WALL PTZ CAMERA 998-6925-000 - PREOWNED

Regular price $1,599.00 USD
Regular price Sale price $1,599.00 USD
Sale Sold out
Shipping calculated at checkout.

In Stock: 2 left

VADDIO REVEAL IN-WALL PTZ CAMERA  998-6925-000

PREOWNED USED BY LARGE CORPORATION - REMOVED FROM WORKING SERVICE

Connectors Two (2) RJ-45 on top of camera enclosure: One (1) for Power and HSDS Video, One (1) for Control
Glass Properties The REVEAL glass It is composed of a liquid crystal matrix, laminated between ITO (Indium tin oxide)
layers and glass. When a charge is applied to the opaque glass, the glass becomes transparent
Camera Properties 1/3-type, 1.3 Megapixel CCD Image Sensor with 18X (f=4.7~84.6mm) Optical Zoom Lens, 1.8 Lux Min.
Illumination (F1.8, 50IRE)
Video Resolutions Supported 1080p/60, 1080p/50, 1080p/30, 1080p/25, 1080i/59.94, 1080i/50, 720p/59.94, 720p/50, 480i/29.97,
576i/25
Pan/Tilt Range and
Field Of View (FOV)
Horizontal Pan: ± 40°, 0°defined as center home position, Approx. 135° total ,
Vertical Tilt: + 25°, - 40°, 0°defined as center home position, Approx. 96° total,
Camera - Horizontal Field of View 55.2° (wide end ) to 3.2° (tele end)
Power Supply 24 VDC, 2.0 Amp PowerRite Power Supply included with AC Cord Sets
Low Voltage DC solution, No AC cabling is required.
Power Consumption 500mA in stand-by frosted opaque mode, 550 mA in clear glass camera on mode
Dimensions (H x W x D) IN-Wall section of back box: 5.75” (146mm) H x 8.5” (216mm) W x 3.85” (98mm) D,
Wall cut out dimensions: 6” (152.4mm) H x 8.75” (222.25) W
Outer Frame Size: 6.75”(171.5mm) H x 11.75” (298.5mm) W
Glass Dimensions: 7.1875” (182.5625mm) H x 12.75” (323.85mm) W x .325” (8.255mm) Thick
Glass Offset from wall: 1.25” (31.75mm)
